High Temperature Accuracy Explosion Type Digital Thermometer Gauge with 12

Package Size30.00cm * 12.00cm * 10.00cm Package Gross Weight1.000kg Product Description:MD-T 2088 Temperature Transmitte

Send inquiry

Basic Info.

Model NO.	MD-T2088
Display Type	LCD
Site Display	Site Display
Accuracy	0.5
IP Rating	IP65
Certification	CE
Customized	Customized
Power Supply	24VDC
Transport Package	Carton
Specification	1.0kg
Trademark	Meokon
Origin	Shanghai
Production Capacity	50000piece/Year

Packaging & Delivery

Package Size30.00cm * 12.00cm * 10.00cm Package Gross Weight1.000kg

Product Description

Product Description:MD-T 2088 Temperature Transmitter is a digital temperature transmitter with display, built-in high-precision temperature sensor, can accurately display the temperature in real time, and can transmit the temperature signal remotely, with high precision and long-term stability.

This temperature transmitter adopts LCD display screen, with various functions such as Celsius/Fahrenheit switching, full-scale correction, digital filtering, etc., simple operation and convenient installation.

This product can measure water, oil, air and other non-corrosive media to stainless steel. The high-precision PT100 is used as the temperature measurement element. The measurement method uses temperature probe contact insertion, and the circuit performs 0-60 ambient temperature compensatiTechnical characteristics:With 4-20mA signal outputOptional probe length, optional temperature rangeExternal power supply 12~28VHigh temperature accuracyUse explosion-proof enclosureSupport customer site temperature calibration and current calibrationAdjustable measurement response speedApplications:Instrumentation matching Laboratory Construction machineryAutomated production line Petrochemical Environmental monitoringSpecification:

High Temperature Accuracy Explosion Type Digital Thermometer Gauge with 12-28V

Temperature Range	-50~300ºC
Accuracy class	±0.5 ±0.25 ±0.1
Long-term stability	0.5% FS/year
Power supply	12~28VDC (24VDC)
Output	4~20mA
Load impedance	≤500Ω
Display screen	4-digit LCD display
Backlight color	White
Measuring medium	Air, water, oil and other non-corrosive media to stainless steel
Shell material	Cast aluminum
Connector Material	304SS (Or customized)
Product Features	Digital filter adjustment,Support customer site temperature calibration and current calibration
